Cold, Hard

Facts

Ice Machine Resources for when you are considering a new ice machine or thinking it's time to upgrade. We've got everything you could ever need to know before you consider buying an ice machine. From frequently asked questions, to installation considerations to pairing the perfect ice machine and ice out-put to your industry. If you’re looking for any ice machine resources, you're at the right place.

ice machine resources

Resources Ice Machine

Resources Ice Machine

Ice Machine Resources

Resources Ice Machine

Installation
Considerations


Utilities


• What are the voltage and amperage characteristics of the electrical outlet that will be used for this ice maker?

• Is there a floor drain within 6 feet (1.8 meters)?

• Is there a water source with water shutoff?

• Are the utilities within 6 feet (1.8 meters) of the ice-maker location?

Access


• Is there an outdoor condenser location above the ice maker?

• Is there easy roof access and penetration?

• Maximum pre-charged tubing line run considerations?

Space


• The ice maker, bin and water filter

• Airflow

NOTE: If the ice maker is tight on space consider a CIM unit, or a top-air discharge ICE unit.

Resources Ice Machine

Ice Machine Resources

Resources Ice Machine

Some Resources for Your Ice Machine

Installation
Considerations


Utilities


• What are the voltage and amperage characteristics of the electrical outlet that will be used for this ice maker?
• Is there a floor drain within 6 feet (1.8 meters)?
• Is there a water source with water shutoff?
• Are the utilities within 6 feet (1.8 meters) of the ice-maker location?


Access


• Is there an outdoor condenser location above the ice maker?
• Is there easy roof access and penetration?
• Maximum pre-charged tubing line run considerations?


Space


• The ice maker, bin and water filter
• Airflow

NOTE: If the ice maker is tight on space consider a CIM unit, or a top-air discharge ICE unit.

Resources Ice Machine

Ice Machine Resources

Resources Ice Machine

Ice Machine Resources

Resources Ice Machine

Installation
Considerations


Utilities


• What are the voltage and amperage characteristics of the electrical outlet that will be used for this ice maker?
• Is there a floor drain within 6 feet (1.8 meters)?
• Is there a water source with water shutoff?
• Are the utilities within 6 feet (1.8 meters) of the ice-maker location?


Access


• Is there an outdoor condenser location above the ice maker?
• Is there easy roof access and penetration?
• Maximum pre-charged tubing line run considerations?


Space


• The ice maker, bin and water filter
• Airflow

NOTE: If the ice maker is tight on space consider a CIM unit, or a top-air discharge ICE unit.

Size
Matters

Does the existing ice maker meet peak usage during the hottest time of the year?
What are the various locations or stations in the establishment that will need ice? Will they be serviced from one or multiple ice makers?
Planning for future growth? Consider building in at least 20 percent additional capacity on new installations.

Size
Matters


Does the existing ice maker meet peak usage during the hottest time of the year?
What are the various locations or stations in the establishment that will need ice? Will they be serviced from one or multiple ice makers?
Planning for future growth? Consider building in at least 20 percent additional capacity on new installations.

Size
Matters


  • Does the existing ice maker meet peak usage during the hottest time of year?

  • What are the various locations or stations in the establishment that will need ice? Will they be serviced from one or multiple ice makers?

  • Planning for future growth? Consider building in at least 20 percent additional capacity on new installations.

NOTE: The chart above outlines the approximate required ice amount per day, depending on application usage. For a detailed calculation based on specific needs, use Ice-O-Matic's interactive Machine Size Calculator.


Food Service

Use Per Day

1.5 lbs (0 .7 kg) per person

Restaurant

3 lbs (1-4 kg) per person per seat

Cocktail

40 lbs per cubic foot (641 kg per cubic meter)

Salad Bar

5 oz. per 7- to 10-oz. drink / 8 oz. per 12-to 16-oz. drink/ 12 oz. per 18-to 24-oz. drink
0.14 kg per 207-296 ml drink/ 0.23 kg per 355-473 ml drink/ 0.34 kg per 532-710 ml drink

Quick Service

Food Service

Use Per Day

1.5 lbs (0 .7 kg) per person

Restaurant

3 lbs (1-4 kg) per person per seat

Cocktail

40 lbs per cubic foot (641 kg per cubic meter)

Salad Bar

5 oz. per 7- to 10-oz. drink / 8 oz. per 12-to 16-oz. drink/ 12 oz. per 18-to 24-oz. drink
0.14 kg per 207-296 ml drink/ 0.23 kg per 355-473 ml drink/ 0.34 kg per 532-710 ml drink

Quick Service

Food Service

Use Per Day

Restaurant

1.5 lbs (0 .7 kg) per person

Cocktail

3 lbs (1-4 kg) per person per seat

Salad Bar

40 lbs per cubic foot (641 kg per cubic meter)

Quick Service

5 oz. per 7- to 10-oz. drink / 8 oz. per 12-to 16-oz. drink/ 12 oz. per 18-to 24-oz. drink, or
0.14 kg per 207-296 ml drink/ 0.23 kg per 355-473 ml drink/ 0.34 kg per 532-710 ml drink

Lodging

Use Per Day



Guest Ice

40 lbs per cubic foot (641 kg per cubic meter)

Restaurant

1.5 lbs (0 .7 kg) per person

Cocktail

3 lbs (1-4 kg) per person per seat

Catering

1 lb (0.45 kg) per person

Lodging

Use Per Day

Guest Ice

40 lbs per cubic foot (641 kg per cubic meter)

Restaurant

1.5 lbs (0 .7 kg) per person

Cocktail

3 lbs (1-4 kg) per person per seat

Catering

1 lb (0.45 kg) per person

Lodging

Use Per Day

Guest Ice

40 lbs per cubic foot (641 kg per cubic meter)

Restaurant

1.5 lbs (0 .7 kg) per person

Cocktail

3 lbs (1-4 kg) per person per seat

Catering

1 lb (0.45 kg) per person


Healthcare

Use Per Day

10 lbs (4.5 kg) per bed

Patient Ice

1 lb (0.45 kg) per person

Cafeteria

Healthcare

Use Per Day

10 lbs (4.5 kg) per bed

Patient Ice

1 lb (0.45 kg) per person

Cafeteria

Healthcare

Use Per Day

Patient Ice

10 lbs (4.5 kg) per bed

Cafeteria

1 lb (0.45 kg) per person

CONVENIENCE STORE

Use Per Day



Beverage

6 oz. per 12-oz. drink/ 10 oz. per 20-oz. drink/ 16 oz. per 32-oz. drink
0.17 kg per 355 ml drink/ 0 .28 kg per 592 ml drink/ 0-45 kg per 946 ml drink

Cold Plate

50% more ice usage per day

Packaged Ice

Weight per bag x number of bags sold per day

CONVENIENCE STORE

Use Per Day

Beverage

6 oz. per 12-oz. drink/ 10 oz. per 20-oz. drink/ 16 oz. per 32-oz. drink
0.17 kg per 355 ml drink/ 0 .28 kg per 592 ml drink/ 0-45 kg per 946 ml drink

Cold Plate

50% more ice usage per day

Packaged Ice

Weight per bag x number of bags sold per day

CONVENIENCE STORE

Use Per Day

Beverage

6 oz. per 12-oz. drink/ 10 oz. per 20-oz. drink/ 16 oz. per 32-oz. drink
0.17 kg per 355 ml drink/ 0 .28 kg per 592 ml drink/ 0-45 kg per 946 ml drink

Cold Plate

50% more ice usage per day

Packaged Ice

Weight per bag x number of bags sold per day

NOTE: The chart above outlines the approximate required ice amount per day, depending on application usage. For a detailed calculation based on specific needs, use Ice-O-Matic's interactive Machine Size Calculator.
NOTE: The chart above outlines the approximate required ice amount per day, depending on application usage. For a detailed calculation based on specific needs, use Ice-O-Matic's interactive Machine Size Calculator.
